.085 in. (2.16mm)
Density
Accessories
Miniature Ribbon
Wire Restraints for Panel-Mount SUPERIBBON? All-Plastic Connectors
Wire restraints provide added security to terminated wires, preventing radial
pullout. They are intended for use on panel mounted connectors where hoods
are not required (wire restraints cannot be applied simultaneously with hoods),
and snap on after connector termination.
Material: Gray UL94V-0 rated polyester.
Ordering Information, SUPERIBBON Wire Restraints
(Two restraints required per connector)
Size
14
24
36
50
64
Plug
97-WR-P14
97-WR-P24
97-WR-P36
97-WR-P50
97-WR-P64
Socket
97-WR-S14
97-WR-S24
97-WR-S36
97-WR-S50
97-WR-S64
Wire Restraints for Panel-Mount Miniature Ribbon Metal Shell Connectors
Metal Shell Wire Restraints serve the same purpose as their SUPERIBBON
counterparts, but are for IDC terminated metal shell connectors. These one-
piece restraints snap in place around the termination area after assembly.
Material: Blue UL94V-0 rated polyester.
Ordering Information, Miniature Ribbon Wire Restraints
(One restraint required per connector)
Size
36
50
Plug or Socket
77-WR-36
77-WR-50
Panel Mounting Clips for All-Plastic Miniature Ribbon Connectors
These clips slip into each end of a modified panel cutout, and allow all-plastic
Miniature Ribbon connectors to be snapped into place and securely front-
mounted to the panel with no additional hardware. Threaded holes are not
required in the panel, and connectors can be loaded without needing access
to the rear of the panel.
Material: Steel
Finish: Tin-cadmium/clear chromate
6
Ordering Information, Panel Mounting Clips
(Two clips required per connector)
Dimensions
B
Chassis
Panel Clip
B
K
Thickness
.062" (1.57mm)
.093" (2.36mm)
Part Number
97-MC-062
97-MC-093
Size
14
24
in
1.417
1.842
mm
35.99
46.79
in
1.060
1.485
mm
26.92
37.72
.125" (3.18mm)
97-MC-125
36
50
2.352
2.947
59.74
74.85
1.995
2.590
50.67
65.79
K
64
3.542
89.97
3.185
80.90
Call Toll Free: 1 (800) 323-9612
6-52
